| Product Name: | Swing Door Motor | Body Size: | 350×83×133mm |
|---|---|---|---|
| Packaging Size: | 535×185×125mm | Fixed Base Size: | 350×83mm |
| Slide Length: | 500mm | Slide Arm Length: | 330mm |
| Motor Speed: | 1800Rpm | Total Weight: | 5.1KG |
| Highlight: | 220V Automatic Door Operators,Swing Automatic Door Operators,110V auto gate opener |
||
[Automatic door opening through disabled button] The door opener can be opened through wireless disabled button or wireless remote key, making it convenient for disabled people to enter safely
If the automatic door opener encounters an object on the closing path, it will automatically reopen the door to ensure the safety of personnel on the door. If used for disabled access, it is recommended to install an optional sports safety scanner to extend the opening time. When an obstacle is detected, it will open the swinging door in reverse.
Durable Motor: The motor adopts wide voltage technology, with an input voltage of AC100V to AC240V, which is very durable and will not easily burn out due to unstable input voltage
[Easy programming and debugging through control board] The parameter program can be easily adjusted through the control board of the automatic swing door, and the door can be set to remain open
[Easy to install] US technical phone support, easy to install and debug.
The H5 is a heavy duty handicap door opener that is activated by wireless handicap buttons for the disabled.This heavy duty swing door system operates in both automatic and manual modes,In manual mode, door opens with very little pressure and closes slowly providing easy operation for handicapped or pedestrians
With advanced wide voltage technique,it makes the swing door operator highly adapt to voltage fluctuations between 110-220VAC +/-10%, it can be used in areas almost of the world whether it is a peak in urban power or insufficient power supply in remote areas.More energy saving and durable than ordinary single input voltage.
The H5 is a heavy duty commercial door opener kit for both inswinging and outswinging doors and two stainless handicap push to exit buttons for automatic doors. This system is designed to secure your door and have the capabilities of automatically and manually opening and closing it as well. A simple yet secure system for areas such as offices, hospitals, elderly homes, banks, commercial locations, and much more.
| Model | H5 |
| Capacity | 180KG |
| Input Voltage | AC 220V/110V ± 10% |
| Output Voltage | DC24V |
|
Motor power
|
30W |
|
Power supply
power
|
160W
|
|
Motor voltage
|
24V
|
|
Remote control
frequency
|
430Mhz
|
|
working
temperature
|
-35℃-85℃
|
| Limit Switch | Spring / Magnetic |
| Noise | ≤60dB |
|
Waterproof level
|
IPX4
|
![]()
![]()
