Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed

Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed
Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed

Large Image :  Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 75
Contact Now Chat Now

Heavy Duty 600kg Max Gate Weight IP65 Waterproof Sliding Gate Motor with 12m/Min Load Speed

Description
IP Class: IP65 Output Power: DC24V
Working Temp: -30℃~+65℃ Specification: 32*26*39cm
Electric Current: AC Max Gate Weight: 600kg/800kg/1200kg/1800kg/2200kg
Noise: ≤50db Driving Type: Electromechanical
Load Speed: 12m/Min Rated Power: 130W
Input Power: AC220V/110V±10% Motor Power: 370W/550W/750W/1200W
Motor Speed: 1400R/MIN Starting Current: 3A
Grounding Resistance: Less Than 4 Ohms
Highlight:

600kg Max Gate Weight Sliding Gate Motor

,

IP65 Waterproof Automatic Gate Motor

,

12m/Min Load Speed Electric Gate Opener

Heavy Duty AC Electric Sliding Motor for Farm Boundary Fence
Product Overview
Heavy duty AC electric sliding gate motor for farm boundary fence
Key Features
  • High Power Options: Motor power 370W/550W/750W/1200W, adapts to 100-2200kg sliding gate weight requirements
  • Stable Operation Performance: Motor speed 1400R/MIN, running speed 12M/MIN, starting current only 3A, low power consumption & high efficiency
  • Wide Temperature Adaptability: Works stably in -25°C to +70°C environment, suitable for various climatic conditions
  • Double Limit Protection: Equipped with magnetic limit switch and spring limit switch, prevents overrun and ensures position accuracy
  • Manual Emergency Function: Clutch device enables manual operation during power failure, turn 90 degrees clockwise with special key for quick switch
  • Reliable Safety Design: Grounding resistance less than 4 ohms, with leakage short circuit protection, weld limit iron block to prevent gate tilting
AC electric sliding motor installation example Heavy duty sliding gate motor components
Technical Specifications
Model MD280 MD370 MD550 MD750 MD1200
Max Gate Weight 600KG 800KG 1200KG 1800KG 2500KG
Rated Power 280W 370W 550W 750W 1200W
Load Speed 12m/min
Input Power AC220V 50HZ / AC110V 60HZ
Output Power DC24V
Limit Switch Magnetic Limit
Noise ≤50dB
Working Temperature -25°C to 70°C
IP Class IP65
Construction & Packaging
Sliding gate motor packaging and delivery Sliding gate motor construction details
  • Aluminum Alloy Shell: Strictly selected aluminum materials according to standards for high-quality products
  • Rust Proof Stainless Steel Gear: Durable, rust resistant, and corrosion-resistant construction
  • Reserve Power Supply: Backup power supply available after power outage for continuous operation
Manufacturer Profile
Sichuan Duoxiang Intelligent Equipment manufacturing facility Sichuan Duoxiang Intelligent Equipment company overview
Sichuan Duoxiang Intelligent Equipment Co., Ltd. is a technology-based enterprise with independent R&D and production capabilities. For decades, we have focused on the R&D and production of access control systems and smartphone access control systems. We have developed a series of high-quality DC sliding door motors, covering brushless DC motors, DC series motors, and AC series motors, with load capacities ranging from 800 kg to 6500 kg, suitable for general residential and industrial applications. These motors include standard speed and high-speed models, featuring excellent soft-start, soft-stop performance, and overall performance. We have become a leading enterprise in the Chinese DC sliding door motor market and hold numerous patents, including a globally unique electronic limit switch. Our products sell well both domestically and internationally and are highly praised by users. We have an independent R&D team and strong R&D capabilities. We provide OEM/ODM services, committed to providing high-quality products, helping partners expand their businesses, and assisting users in achieving smarter goals.
Sichuan Duoxiang product application examples Sichuan Duoxiang quality control processes
Frequently Asked Questions
  • Is there any inventory available?
    Having sufficient inventory; 100 sets of inventory for each type of product; Inventory products are in neutral packaging without brand
  • Delivery Time
    Ship on the same day or the next day after receiving payment
  • Customized Content
    Product logo customization: For machines with more than 20 sets, logos can be customized for free; Customization of outer packaging: Free customization of outer packaging for more than 100 sets
  • After-Sales Service
    Most products have a one-year warranty period starting from receipt of goods; Free accessories provided during warranty period (excluding shipping costs); Free technical support provided
