China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed

China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed
China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed

Large Image :  China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 75
Contact Now Chat Now

China Made Heavy Duty AC Automatic Gate Motor Sliding Gate Opener 600-2200kg Max Weight IP55 Waterproof 12m/min Speed

Description
Dimensions: 32*26*39cm Limit Switch: Spring Limit/Magnetic Limit
Working Temp: -30℃~+65℃ Driving Type: Electromechanical
Load Speed: 12m/Min Output Power: DC24V
IP Class: IP55 Electric Current: AC
Max Gate Weight: 600kg/800kg/1200kg/1800kg/2200kg Rated Power: 130W
Noise Level: ≤50db Input Power: AC220V/110V±10%
Motor Speed: 1400R/MIN Starting Current: 3A
Grounding Resistance: Less Than 4 Ohms
Highlight:

600-2200kg Max Gate Weight Automatic Gate Motor

,

IP55 Waterproof Sliding Gate Opener

,

12m/min Load Speed Gate Operator

AC Automatic Gate Opener - Heavy Duty Sliding Gate Motor 600-2000kg
High-performance automatic gate opener designed for industrial and residential applications with robust construction and reliable operation.
Heavy duty sliding gate motor installation
Key Features
  • Multiple power options: 370W/550W/750W/1200W motors adapt to 100-2200kg sliding gate weight requirements
  • Stable operation: 1400R/MIN motor speed, 12M/MIN running speed, and only 3A starting current for low power consumption
  • Wide temperature range: Operates reliably in -25°C to +70°C environments for various climate conditions
  • Double limit protection: Magnetic limit switch and spring limit switch prevent overrun and ensure precise positioning
  • Manual emergency function: Clutch device enables manual operation during power failure with 90-degree clockwise key rotation
  • Advanced safety design: Grounding resistance less than 4 ohms with leakage and short circuit protection
Gate motor internal components Gate motor installation example
Technical Specifications
Model MD280 MD370 MD550 MD750 MD1200
Max Gate Weight 600KG 800KG 1200KG 1800KG 2500KG
Rated Power 280W 370W 550W 750W 1200W
Load Speed 12m/min
Input Power AC220V 50HZ / AC110V 60HZ
Output Power DC24V
Noise Level ≤50dB
Working Temperature -25°C to 70°C
IP Class IP65
Packaging & Construction
Gate motor packaging Gate motor construction details
Aluminum Alloy Shell: Strictly selected aluminum materials according to standards for high-quality durability
Stainless Steel Gear: Rust-resistant and corrosion-resistant for long-lasting performance
Backup Power Supply: Reserve power capability available after power outages
Manufacturer Profile
Sichuan Duoxiang Intelligent Equipment facility Sichuan Duoxiang Intelligent Equipment products
Sichuan Duoxiang Intelligent Equipment Co., Ltd. is a technology-based enterprise with independent R&D and production capabilities. For decades, we have specialized in access control systems and smartphone access control solutions. Our product range includes high-quality DC sliding door motors covering brushless DC motors, DC series motors, and AC series motors with load capacities from 800kg to 6500kg. We offer standard speed and high-speed models with excellent soft-start and soft-stop performance, holding numerous patents including a globally unique electronic limit switch.
Sichuan Duoxiang manufacturing process Sichuan Duoxiang quality control
Frequently Asked Questions
Is there any inventory available?
We maintain sufficient inventory with 100 sets of each product type in neutral packaging without branding.
What is the delivery time?
Shipment occurs on the same day or next day after receiving payment.
What customization options are available?
Product logo customization for orders of 20+ sets and outer packaging customization for 100+ sets, both free of charge.
What is the after-sales service policy?
Most products include a one-year warranty from receipt date, with free accessories during warranty period (excluding shipping) and complimentary technical support.
